Olec OLITE - AL 20, al 19 Capacitor Assembly; AL 15 Capacitor Assembly

94MS20 Rev. B4 5-11
AL 20, AL 19 Capacitor Assembly
BROWN
55SW01
BLACK
YELLOW
BLUE
ORANGE
3µƒ 9µƒ
10µƒ 10µƒ
10µƒ
BLUE
YELLOW
YELLOW
ORANGE
AL 15 Capacitor Assembly
WIRES
FROM
HARNESS
1
3
5
5
1
3
Old Style
AL 15 with L1150A Lamp
WIRES FROM HARNESS
1 35
3
5
7
CAPACITOR ASSEMBLY PART # 62D139
New Style
AL 15 with L1150A Lamp
Old Style
AL 15 with L1150B Lamp
8µƒ
16µƒ
8µƒ
8µƒ
8µƒ
8µƒ
WIRES
FROM
HARNESS
1
3
5
5
1
3
8µƒ
8µƒ
8µƒ
8µƒ
8µƒ
16µƒ
16µƒ
16µƒ
WIRES FROM HARNESS
1 35
3
5
7
CAPACITOR ASSEMBLY PART # 62D139
New Style
AL 15 with L1150B Lamp
16µƒ
16µƒ
16µƒ
16µƒ
