Olec OLITE - AL54;55 Ballast and Tap Switch Wiring

94MS20 Rev. B4 4-3
AL56-480 Ballast Wiring
COM
277
CAP
277
CAP
COM
BALLAST
#1
L1 L2
T1 T2
RED
BLK
TERMINAL STRIP
CAP
277
COM
COM
277
CAP
29 (VIOLET).
NO. 20 (ORANGE
TO CAP. PACK).
AC IN
6 GA.
(BLK) (BLK) (RED)
1618 17 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
(RED)
BALLAST
#2
BALLAST
#4
BALLAST
#3
CONTACTOR
AL54 / AL55 Ballast / Tap Switch Wiring
COM
208
240
CAP
240
CAP
208
COM
BALLAST
#1
BALLAST
#2
L1
ORANGE TO
CAP. PACK
L2
T1 T2
RED
BLK
CAP
240
208
COM
BALLAST
#4
COM
208
240
CAP
BALLAST
#3
1
2
3
4
5
6
10
11
12
VOLTAGE SELECTOR SWITCH
YELLOW TO
AUTOFORMER
RED TO FUSE
AUTOFORMER
240 VOLT
AC IN
10 GA.
1618 17 15 14 13 12 11 10 9 8 7 6 5 4 3 2 1
TERMINAL STRIP
CONTACTOR
