3. Other Field Service Ver. 2.0 Jan. 2008
8
SD-505
Maintenance
6. Pull the lock release lever [1], and
open the saddle unit.
7. Remove the screw [2].
8. Remove two screws [1], and remove
the saddle unit [2].
4511F2C558DA
[2]
[1]
4511F2C559DA
[1]
[2]
Service Manual Y108482-2
