Field Service Ver. 2.0 Jan. 2008 6. Finisher operations
29
SD-505Adjustment / Setting
6.2 Finisher Check modes
A. Fold Drive
• Performs the creasing drive once.
o Raises the layable guide.
o Stops after the predetermined time.
o Lowers the layable guide.
o The operation is finished.
B. Saddle Outlet Open&Close
• Opens the saddle exit after the saddle exit is opened and closed.
o Stops after the predetermined time.
o The saddle exit closes.
o The saddle in & out guide advances.
o Stops after the predetermined time.
o The saddle in & out guide retracts.
o The operation is finished.
C. Conveyance Drive
• Transport drive is performed for the predetermined time. (Performs the same transport
drive as the pre-drive with the high speed of the connected copier.)
o Drives the entrance motor (M1).
o Drives the transport motor/1 (M2).
o Drives the transport motor/2 (M3).
o Drives the exit motor (M4).
o The operation is finished.
• If the mail bin kit MT-502 is installed, the mail bins are also driven.
• If the saddle kit SD-505 is also installed, the saddle transport motor (M8) is also driven.
Y108482-2 Service Manual
