Field Service Ver. 2.0 Jan. 2008 1. Product specification
1
SD-505General
Outline
1. Product specification
A. Type
B. Paper
C. Machine specifications
*1: Size when the paper output tray is pulled out
D. Operating environment
• Conforms to the operating environment of the main body.
E. Consumables
• Staples 2000 (MS-2C) x 2
NOTE
• These specifications are subject to change without notice.
Name Saddle sticher SD-505
Type Built into the finisher
Installation Screwed to the finisher
Document alignment Center
Stapling function
Center parallel two points
No. of sheets to be stapled together: 2 to 15
Ty p e
Plain paper
60 g/m
2
to 90 g/m
2
16 to 24 lb
Recycled paper
Thick paper
91 g/m
2
to 209 g/m
2
24.25 to 55.5 lb
Size
B5S to A3
8-
1
/
2
x 11S to 11 x 17
Capacity 200 sheets or 20 copies
Power requirements
DC 24 V (supplied from the finisher)
DC 5 V
Max. power consumption 9.5 W or less
Dimensions
Crease unit
48 mm (W) x 399 mm (D) x 121 mm (H)
2 inch (W) x 15.75 inch (D) x 4.75 inch (H)
Saddle unit
445 mm (W) x 478 mm (D) x 203 mm (H)
17.5 inch (W) x 18.75 inch (D) x 8 inch (H)
576 mm (W) x 478 mm (D) x 281 mm (H) *1
22.75 inch (W) x 18.75 inch (D) x 11 inch (H) *1
Weight
Crease unit 1.9 kg (0.5 lb)
Saddle unit 7.4 kg (2.0 lb)
Y108482-2 Service Manual
