Field Service Ver. 2.0 Jan. 2008 5. Sensor check
27
SD-505Adjustment / Setting
5.1.2 Sensor check list
A. Sensors 4
Symbol Panel display Part/Signal name
Operation characteris-
tics/Panel display
10
PS20
Sensors monitor4
Saddle exit Saddle exit sensor
Paper
present
Paper not
present
PS22 Folding R home Crease roller home position sensor
Paper
present
Paper not
present
SW5 Middle guide Middle guide switch Open Closed
PS24 Saddle guide Layable guide home sensor Blocked Unblocked
— Saddle stapler 1
— Home Staple Home Position Sensor 1 Blocked Unblocked
— Staple empty Staple Empty Detection Sensor 1 Blocked Unblocked
— Self priming Self-Priming Sensor 1 Blocked Unblocked
— Saddle stapler 2
— Home Staple Home Position Sensor 2 Blocked Unblocked
— Staple empty Staple Empty Detection Sensor 2 Blocked Unblocked
— Self priming Self-Priming Sensor 2 Blocked Unblocked
SW4 Saddle Saddle opening switch Open Closed
PS21 Saddle empty Saddle tray empty sensor
Paper
present
Paper not
present
PS18 Home (Saddle exit) Saddle exit roller home position sensor
Paper
present
Paper not
present
Y108482-2 Service Manual
