3. Other Field Service Ver. 2.0 Jan. 2008
10
SD-505
Maintenance
7. Disconnect the connector [1].
8. Remove three screws [1], and
remove the crease unit [2].
NOTE
• When the punch kit is mounted,
remove the punch kit first.
4511F2C563DA
[1]
4511F2C564DA
[1]
[1]
[1]
[2]
Service Manual Y108482-2
