10-019116-01EN, Rev. 2, January 2021
Chapter 124
The Ethernet cable has Power over Ethernet (PoE+) enabled and connects to an
Ethernet network capable of providing 30 W input power.
Safe and proper handling of cables and cords
• Connect the power cords to a properly grounded and easily accessible power
outlet.
• Do not defeat or bypass the ground conductor.
• Install all cords in accordance with applicable regulations.
1.9 Indicators and Statuses
The Vanta iX XRF analyzer has several indicators that alert the operator to the status
of the unit.
1.9.1 Power Indicator
The power button ( ) is back lit, so it also serves as the power indicator.
1.9.2 Radiation LED
A radiation LED is connected to the LED port through the radiation LED cable
assembly. When the radiation LED is ON:
• The X-ray tube is powered to full operational capacity.
• The Vanta iX is emitting X-ray radiation through the measurement window.
1.10 Safety Administration
This section provides information regarding the following radiation safety measures:
• Radiation safety training recommendations
• Dosimeter badges
• Dosimeter safety program
• Dosimeter suppliers
• Registration requirements
