10-019116-01EN, Rev. 2, January 2021
Radiation Profile 63
6. Top (up to front cover seam)
7. Left side (behind scatter plane)
8. Right side (behind scatter plane)
9. Top (rear up to scatter plane)
10. Bottom (under the instrument)
Figure B-1 Test setup and survey diagram
①
②
③④
⑤
⑦⑧
⑨
⑩
⑥
②
