Installation 35
3. Installation
This chapter provides information about installing the Vanta iX.
Carefully read “Safety Information” on page 19 before applying power to the Vanta iX
XRF analyzer. Misuse of the Vanta iX could result in serious illness or injury.
3.1 I/O Panel
The I/O panel contains all of the Vanta iX I/O connectors (Figure 3-1 on page 36):
1. DC power connector
2. USB A connector
3. Ethernet connector
4. LED (radiation, light emitting diode) connector
5. Customer I/O connector
6. Olympus I/O connector
