10-019116-01EN, Rev. 2, January 2021
Chapter 342
To power on the XRF analyzer
Press and hold the power button ( ) for one second.
To power off the XRF analyzer
Press and hold the power button ( ) for one second.
To power off the XRF analyzer under emergency conditions
If the radiation LED remains illuminated or blinking, and you believe that the
Vanta iX is “locked” in an on state, follow the instructions listed below.
Press and hold the power button ( ) for ten seconds.
3.3 Mounting Instructions
The drawings in Figure 3-9 on page 43 to Figure 3-13 on page 47 show the following:
• Dimensions of the Vanta iX
• Locations of the mounting holes
• Compatibility information for selecting the correct screw type for the mounting
holes
All dimensions are in millimeters unless otherwise noted.
