Olympus Vanta iX Series User Manual

10-019116-01EN, Rev. 2, January 2021
Chapter 456
3. Orient the faceplate with the latch and the cutout on the probe (Figure 4-9 on
page 56).
Figure 4-9 Orienting faceplate with latch and probe cutout
4. Slide the faceplate into the cutout on the probe, making sure the faceplate
alignment tab is inserted into the tab slot (Figure 4-10 on page 56).
Figure 4-10 Inserting alignment tab into tab slot
Probe cutout
Latch
Alignment tab slot
Alignment tabFaceplate catch
