Radiation Profile 61
Appendix B: Radiation Profile
The tables below represent upper bounds on the worst case maximum power and
minimum beam filtration using a 316 stainless steel target. More specifically, the
Vanta iX was operating at either 40 kV, 100 µA w/2 mm Al filter (model VIX-CW); or,
50 kV (model VIX-MR), 80 µA, 350 µm Cu filter. Note that these beam conditions do
not represent typical use values or a combination of settings typically available from
the factory.
Table 11 Maximum Leakage radiation measured at 40 kV in µSv/h
Surveyed location Close 10 cm 30 cm
Front
BK
a
a. BK = background reading (< 1 µSv/h). To convert from µSv/h to mR/h, divide value by 10.
BK
*
BK
*
Left Side (front of scatter plane) 24 4.8 1.2
Right Side (front of scatter plane) 11.1 1.9
BK
*
Top (up to front cover seam) 16.7 2.9 1.1
Left Side (behind scatter plane)
BK
*
BK
*
BK
*
Right Side (behind scatter plane)
BK
*
BK
*
BK
*
Top (rear up to scatter plane)
BK
*
BK
*
BK
*
Bottom
BK
*
BK
*
BK
*
