Omicron Bode 100 User Manual

31
Gain/Phase Mode
Congratulation! You learned how to use the Gain/Phase mode.
How to:
• Measure the gain and phase shift of a DUT using a sinusoidal signal at a
certain frequency
• Set the bandwidth, attenuators and amplitude of the Bode 100
• Optimize the diagram
• Compensate the connection cables in the Gain/Phase mode
As OMIfuzius said: Only
applied knowledge
changes the world. We
are responsible to
change it to the better.
Go back to the overview chart at 3 "Gain/Phase Mode" on page 17 and try
different settings to check out their effect on the measurement.
