Bode 100 User Manual

9. After the calibration has been finished, the calibration window looks like

shown below.

Hint: The warning symbol indicates that the load resistor and/or the short

delay time value differ from the factory settings.

10.Click . You have done the Impedance calibration in the

Frequency Sweep mode.

11.Reconnect the quartz filter to the Bode 100 as shown below.
