81
Calibrating the Bode 100
8. In the respective calibration window, click the Start button next to Thru to
calibrate the Bode 100.
Note: In the Gain/Phase mode, no Impedance calibration is possible.
The Gain/Phase mode is now calibrated for the current specific
measurement setup. Refer to 7.1 "Calibration Methods" on page 75 to learn
in which cases you have to repeat the calibration if a parameter is changed.
9. Click .
In our case we read 101
μdB (0.000101 dB) and 0.001º. Because we are
close to zero your results may differ from this example. Nevertheless the
displayed values should be very small.
