Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3E W161 Braking Resistor
Thermal Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 100.0
0.0 --- % Possible
(TxPDO)
4F W178 Number of Start-
ups
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 655.35
1.00 to 10,000
0.00 --- --- Possible
(TxPDO)
50 W179 Total RUN Time
Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 655,350
0 --- h Possible
(TxPDO)
51 W180 Tuning Progress
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 100
0 --- % Possible
(TxPDO)
3018 03 W202 Reserved Do not use. --- --- --- ---
04 W203 Reserved Do not use. --- --- --- ---
A-4-3
Z Group Parameter List (Alarm Information 1)
Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3012 01 Z00 Second Last
Alarm Info. Out-
put Frequency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 655.35
0 --- Hz Possible
(TxPDO)
02 Z01 Second last
Alarm info. Out-
put Current
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 655.35
0 --- A Possible
(TxPDO)
03 Z02 Second last
Alarm info. Out-
put Voltage
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 1,000
0 --- V Possible
(TxPDO)
04 Z03 Second Last
Alarm Info. Tor-
que Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
-999 to 999
0 --- % Possible
(TxPDO)
05 Z04 Second Last
Alarm Info. Fre-
quency Com-
mand
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 655.35
0 --- Hz Possible
(TxPDO)
Appendices
A-74
M1 Series EtherCAT Type User’s Manual (I670)
