Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
2E A45 Speed Control 2
P Proportional
Gain
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.1 to 200.0
10
√
--- Possible
2F A46 Speed Control 2 I
Integral Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.001 to 9.999
999: Disable
0.1
√
s Possible
30 A47 Speed Control 2
FF Gain
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 99.99
0
√
s Possible
31 A48 Speed Control 2
Output Filter
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.000 to 0.100
0.002
√
s Possible
32 A49 Speed Control 2
Notch Filter Res-
onance Frequen-
cy
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
1 to 500
200
√
Hz Possible
33 A50 Speed Control 2
Notch Filter At-
tenuation Level
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 40
0
√
dB Possible
34 A51 2nd Cumulative
Motor Run Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 9,999
The cumulative motor run time can
be modified or reset.
0 --- 10 h Possible
35 A52 2nd Startup
Counter for Mo-
tor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 65,535
Cleared to 0 by the writing of 0
0
√
--- Possible
36 A53 2nd Motor 2 %X
Correction Factor
1
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0 to 300
100
√
% Possible
38 A55 Torque Current
for 2nd Vector
Control
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 500.0
16.71 --- A Possible
39 A56 Induced Voltage
Factor for 2nd
Vector Control
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
50 to 100
95 --- % Possible
Appendices
A-151
M1 Series EtherCAT Type User’s Manual (I670)
A-4 Lists of Manufacturer Specific Objects 2
(Inverter Parameters)
A
A-4-10 A Group Parameter List (Motor 2 Parameters)
