Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3A A57 Reserved Do not use. --- --- --- ---
3D A60 2nd Speed Con-
version Coef
fi-
cient
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00: Using E50 value
0.01 to 600.00
0
√
--- Possible
3E A61 2nd Display Co-
ef
ficient for
T
ransport time /
Auxiliary Display
Coefficient for
Speed Monitor
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.000 to 9,999
1
√
--- Possible
3F A62 2nd Starting Fre-
quency Holding
T
ime
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 10.00
0.00
√
s Possible
40 A63 2nd Stop Fre-
quency
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.0 to 60.0
999: According to F25
*1
999
√
Hz Possible
41 A64 2nd Stop Fre-
quency Detection
Method Selection
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0: Output frequency, Detected speed
1: Frequency reference
100: According to F38
100 --- --- Possible
42 A65 2nd Stop Fre-
quency Holding
Time
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.00 to 10.00
0.00
√
s Possible
*1. For SDO communications and PDO communications, it is 7FFF hex.
A-4-11
b Group Parameter List (Velocity Control 3)
Index
(hex)
Sub-
index
(hex)
Pa-
rame-
ter No.
Function name Monitor or data range
Default
data
Set-
ting
dur-
ing
RUN
Unit
PDO
map
3013 2C b43 Speed Control 3
Speed Command
Filter
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.000 to 5.000
0.02
√
s Possible
2D b44 Speed Control 3
Speed Detection
Filter
V/f DTV
PG V/f PG DTV
SLV PGV PM SLV PM PGV
0.000 to 0.100
0.005
√
s Possible
Appendices
A-152
M1 Series EtherCAT Type User’s Manual (I670)
