DeviceNet Explicit Messages Appendix 1
Setting and Monitoring Operation Time
Explicit
message
Read
/write
Function Command Response
Data size
Service
Code
Class
ID
Instance
ID
Attribute
ID
Data size
Set Value for
Operation Time
Monitor
Read Reads the monitor
value for the time
(unit: ms) from when
the output (1 to 8)
specified by the
instance ID turns
ON until the corre-
sponding input turns
ON.
0E hex 97 hex 01 to 08
hex
67 hex - 2 bytes
0000 to FFFF hex
(0 to 65535)
Write Writes the monitor
value for the time
(unit: ms) from when
the output (1 to 8)
specified by the
instance ID turns
ON until the corre-
sponding input turns
ON.
10 hex 97 hex 01 to 08
hex
67 hex 2 bytes
0000 to
FFFF hex
(0 to 65535)
Present Value
for Operation
Time Monitor
Read Reads the present
value for the time
(unit: ms) from when
the output (1 to 8)
specified by the
instance ID turns
ON until the corre-
sponding input turns
ON.
0E hex 97 hex 01 to 08
hex
65 hex - 2 bytes
0000 to FFFF hex
(0 to 65535)
Monitor Status
Value for Oper-
ation Time
Monitor Read
Read Reads the monitor
status for the time
(unit: ms) from when
the output (1 to 8)
specified by the
instance ID turns
ON until the corre-
sponding input turns
ON.
0E hex 97 hex 01 to 08
hex
66 hex - 1 byte
00 hex: Within
range
01 hex: Over
range (over the
monitor value)
