Logic Functions Section 1-5
Data That Can Be Set for Safety Input Logic Result or Remote I/O
The following data is used for remote I/O data. For details on remote I/O allo-
cations, refer to 3-2-4 I/O Assembly Data.
Or
Example 1: Outputs 0 and 1 Used in Single Channel Mode
Output 0 output condition signal: Bit 0 output condition signal 0
(0/1) is used.
Output 1 output condition signal: Bit 1 output condition signal 1
is used.
Example 2: Outputs 0 and 1 Used in Dual Channel Mode
Output 0 output condition signal: Bit 0 output condition signal 0
(0/1) is used.
Output 1 output condition signal: Setting not required.
Data That Can Be Set for Feedback Signals
Name Option Setting range
Output condi-
tion signal
Remote I/O Data received from Safety Master or Standard Master through the
network
IN0 to IN5 Safety input logic operation result
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Safety
output
terminal
7, output
condition
signal 7
Safety
output
terminal
6, output
condition
signal 6
(6/7)
Safety
output
terminal
5, output
condition
signal 5
Safety
output
terminal
4, output
condition
signal 4
(4/5)
Safety
output
terminal
3, output
condition
signal 3
Safety
output
terminal
2, output
condition
signal 2
(2/3)
Safety
output
terminal
1, output
condition
signal 1
Safety
output
terminal
0, output
condition
signal 0
(0/1)
Bit 7 Bit 6 Bit 5 Bit 4 Bit 3 Bit 2 Bit 1 Bit 0
Output
condition
signal 7
Output
condition
signal 6
(6/7)
Output
condition
signal 5
Output
condition
signal 4
(4/5)
Output
condition
signal 3
Output
condition
signal 2
(2/3)
Output
condition
signal 1
Output
condition
signal 0
(0/1)
Name Option Setting range
Feedback
signal
IN4 Use the IN4 terminal as the feedback input terminal.
IN5 Use the IN5 terminal as the feedback input terminal.
IN6 Use the IN6 terminal as the feedback input terminal.
IN7 Use the IN7 terminal as the feedback input terminal.
