Remote I/O Allocations Section 3-2
The following I/O data can be selected from the Network Configurator.
DST1-XD0808SL-1
The default values for the I/O assembly data are as follows:
Safety connections:
Standard connection: The default values for each type of connection are
given below.
The following I/O data can be selected from the Network Configurator.
Safety connection
Standard connection
Network Configurator
setting
Assembly Instance No.
I/O size (bytes)
Inputs Outputs
Safety Input Data
Combined Safety Input Status
Individual Safety Input Status
Combined Safety Output Status
Individual Safety Output Status
Muting Lamp Status
Safety Output Monitors
Individual Test Output Status
General Status
Safety Output Data
Standard Output Data
√√Safety input assembly 1 203 Input 1 √
√√Safety input assembly 2 330 Input 1 √√√√
√√Safety input assembly 3 331 Input 2 √√√√
√√Safety input assembly 4 332 Input 3 √ √ √√√
√√Safety input assembly 5 333 Input 3 √ √ √√√√
√√Standard output assembly 21 Output 1 √
√ Safety output assembly 1 233 Output 1 √
√ Safety output assembly 2 350 Output 1 √√
√ General status assembly 300 Input 1 √
√ Output monitor/test out-
put status with general
status assembly
342 Input 2 √√√
Default (Assembly instance number)
IN Safety input assembly 1 (Instance No. 204)
OUT Safety output assembly 1 (Instance No. 352)
Connection Default (Assembly instance number)
Poll IN Safety input assembly 3 (No. 3A1)
OUT None
Bit strobe IN Safety input assembly 3 (No. 3A1)
OUT None
COS IN Safety input assembly 3 (No. 3A1)
OUT None
Cyclic IN Safety input assembly 3 (No. 3A1)
OUT None
