Remote I/O Allocations Section 3-2
The following I/O data can be selected from the Network Configurator.
DST1-MRD08SL-1
The default values for the I/O assembly data are as follows:
Safety connections:
Standard connection: The default values for each type of connection are
given below.
Safety connection
Standard connection
Network Configurator
setting
Assembly Instance No.
I/O size (bytes)
Inputs Outputs
Safety Input Data
Combined Safety Input Status
Individual Safety Input Status
Combined Safety Output Status
Individual Safety Output Status
Muting Lamp Status
Safety Output Monitors
Individual Test Output Status
General Status
Safety Output Data
Standard Output Data
√√Safety input assembly 1 204 Input 1 √
√√Safety input assembly 2 320 Input 2 √√√√
√√Safety input assembly 3 321 Input 4 √√√√
√√Safety input assembly 4 322 Input 5 √ √ √√√
√√Safety input assembly 5 323 Input 5 √ √ √√√√
√√Standard output assembly 21 Output 1 √
√ Safety output assembly 1 234 Output 1 √
√ Safety output assembly 2 351 Output 2 √√
√ General status assembly 300 Input 1 √
√ Output monitor/test out-
put status with general
status assembly
341 Input 3 √√√
Default (Assembly instance number)
IN Safety input assembly 1 (Instance No. 203)
OUT Safety output assembly 1 (Instance No. 233)
Connection Default (Assembly instance number)
Poll IN Safety input assembly 5 (No. 333)
OUT Standard output assembly (No. 21)
Bit strobe IN Safety input assembly 5 (No. 333)
OUT None
COS IN Output Monitor/Test Out status with General status
assembly (No. 342)
OUT None
Cyclic IN Output Monitor/Test Out status with General status
assembly (No. 342)
OUT None
