6 Parameters
6 - 96
E5@C-T Digital Temperature Controllers User’s Manual (H185)
lbal
LBA Level
A Standard Model must be used.
Alarm 1 must be assigned.
The alarm type must be set to 12 (LBA).
The LBA detection time must not be 0.
• This parameter sets the LBA level.
• If the deviation between the SP and PV exceeds the LBA level, a loop burnout is
detected.
* For ON/OFF control, the LBA Detection Time parameter (advanced function setting level) must not
be set to 0.
For 2-PID control, the LBA Detection Time parameter must not be set to 0 for any of PID sets 1 to
8.
z Related Parameters
Process Value/Set Point (Operation Level): Page 6-8
Alarm 1 to 4 Type (Initial Setting Level): Page 6-66
PID*LBA detection time (PID setting level): Page 6-49
LBA Detection Time (Advanced Function Setting Level): Page 6-95
LBA Band (Advanced Function Setting Level): Page 6-96
lbab
LBA Band
A Standard Model must be used.
Alarm 1 must be assigned.
The alarm type must be set to 12 (LBA).
The LBA detection time must not be 0.
• This parameter sets the LBA band.
• If a control deviation greater than the LBA band is not reduced when the LBA level is
exceeded, an loop burnout is detected.
* For ON/OFF control, the LBA Detection Time parameter (advanced function setting level) must not
be set to 0.
For 2-PID control, the LBA Detection Time parameter must not be set to 0 for any of PID sets 1 to
8.
z Related Parameters
Process Value/Set Point (Operation Level): Page 6-8
Alarm 1 to 4 Type (Initial Setting Level): Page 6-66
PID*LBA detection time (PID setting level): Page 6-49
LBA Detection Time (Advanced Function Setting Level): Page 6-95
LBA Level (Advanced Function Setting Level): Page 6-96
Function
Setting
Setting range Unit Default
Temperature input 0.1 to 999.9 °C or °F8.0
Analog input 0.01 to 99.99 %FS 10.00
See
See
Function
Setting
Setting range Unit Default
Temperature input 0.0 to 999.9 °C or °F3.0
Analog input 0.00 to 99.99 %FS 0.20
See
See
