Omron E5*C Series User Manual

6 - 97
6 Parameters
E5@C-T Digital Temperature Controllers User’s Manual (H185)
6-10 Advanced Function Setting Level
6
out1
Control Output 1 Assignment A Standard Model must be used.
out2
Control Output 2 Assignment
A Standard Model with two control outputs must be
used.
• These parameters set the function to assign to control outputs 1 and 2.
*1 If c-o is assigned for standard control, a value equivalent to 0% is output.
*2 Can be selected for relay and voltage outputs (for driving SSR) only.
*3 WR1 to WR8 are not displayed when the logic operation function is not used.
*4 If the Standard or Heating/Cooling parameter is set to heating/cooling control, control
automatically switches to c-o.
Function
Setting
Setting range Default
none: Disabled Control Output 1 Assignment: o
Control Output 2 Assignment: none
*4
o: Control output (heating)
c-o:
Control output (cooling)
*1
alm1:
Alarm 1
*2
alm2:
Alarm 2
*2
alm3:
Alarm 3
*2
alm4:
Alarm 4
*2
ha:
Heater alarm
*2
hb:
HB alarm
*2
hs:
HS alarm
*2
s.err:
Input error
*2
p.end:
Program end output
*2
stg:
Stage output
*2
run:
RUN output
*2
ts1:
Time signal 1 output
*2
ts2:
Time signal 2 output
*2
alm:
Integrated Alarm
*2
wr1:
Work bit 1
*2*3
wr2:
Work bit 2
*2*3
wr3:
Work bit 3
*2*3
wr4:
Work bit 4
*2*3
wr5:
Work bit 5
*2*3
wr6:
Work bit 6
*2*3
wr7:
Work bit 7
*2*3
wr8:
Work bit 8
*2*3
