Omron E5*C Series User Manual

6 Parameters
6 - 98
E5@C-T Digital Temperature Controllers User’s Manual (H185)
sub1
Auxiliary Output 1 Assignment There must be an auxiliary output 1.
sub2
Auxiliary Output 2 Assignment There must be an auxiliary output 2.
sub3
Auxiliary Output 3 Assignment There must be an auxiliary output 3.
sub4
Auxiliary Output 4 Assignment There must be an auxiliary output 4.
• These parameters set the function to assign to auxiliary outputs 1 to 4.
*1 If c-o is assigned for standard control, a value equivalent to 0% will be output.
*2 If heating/cooling control is used with an E5CC-T Controller that does not have control output 2,
c-o is automatically assigned to auxiliary output 2. If heating/cooling control is used with an
E5EC-T/AC-T Controller that does not have control output 2, c-o is automatically assigned to
auxiliary output 4.
*3 WR1 to WR8 are not displayed when the logic operation function is not used.
*4 If the Controller is equipped with HB/HS alarm detection, it is set by default to ha (Heater Alarm).
Setting range Default
none: Disabled
Auxiliary Output 1 Assignment: alm1
*4
Auxiliary Output 2 Assignment: alm2
*2
Auxiliary Output 3 Assignment: alm3
*2
Auxiliary Output 4 Assignment: alm4
*2
o: Control output (heating)
c-o:
Control output (cooling)
*1
alm1:
Alarm 1
alm2:
Alarm 2
alm3:
Alarm 3
alm4:
Alarm 4
ha:
Heater alarm
hb:
HB alarm
hs:
HS alarm
s.err:
Input error
p.end: Program end output
stg: Stage output
run: RUN output
ts1: Time signal 1 output
ts2: Time signal 2 output
alm:
Integrated Alarm
wr1:
Work bit 1
*3
wr2:
Work bit 2
*3
wr3:
Work bit 3
*3
wr4:
Work bit 4
*3
wr5:
Work bit 5
*3
wr6:
Work bit 6
*3
wr7:
Work bit 7
*3
wr8:
Work bit 8
*3
