8.3 Operation level ( )
8-9
Setting data
● Related setting data
"PV/SP" (Operation level)(P.8-7)
"SP mode" (Adjustment level) (P.8-14)
"Remote SP ramp rise value" "Remote SP lower limit" (Input initial
setting level) (P.8-38)
"Control mode" (Control initial setting level) (P.8-43)
• Monitors the SP during ramp.
• The ramp function limits the rate of change of the SP.
• The setting is only displayed if a value is entered for "SP ramp rise
value" or "SP ramp fall value".
• For other than ramp, the SP value is the same as in "PV/SP".
● Related setting data
"PV/SP" (Operation level)(P.8-7)
"SP ramp time unit", "SP ramp rise value", "SP ramp fall value"
(Adjustment level) (P.8-18)
"SP upper limit", "SP lower limit" (Control initial setting level) (P.8-43)
Monitors the heating MV during operation.
• Monitors the MV of standard control and the heating MV of heating/
cooling control.
Reference
Reference
Ramp SP monitor
sp-m
SP ramp rise value ≠ 0 or SP ramp fall value ≠ 0
CH
Function
Monitor
Monitor range Units
SP lower limit to SP upper limit EU
Reference
Reference
MV monitor (heating)
o
Standard control, heating/cooling control
CH
Function
Monitor
Control Monitor range Units
Standard -5.0 to 105.0 %
Heating/
cooling
0.0 to 105.0 %
