Section 8 Setting data
8-10
Setting data
Monitors the cooling MV during operation.
• Monitors the cooling MV during heating/cooling control
● Related setting data
"Control mode" (Control initial setting level) (P.8-43)
Monitors the amount of valve opening during operation.
• Monitors the amount of valve opening during position proportional
control.
• A potentiometer can be connected and "Motor calibration" can be
executed to monitor the amount of valve opening.
● Related setting data
"Control mode" (Control initial setting level) (P.8-43)
"Motor calibration" (Control initial setting 2 level) (P.8-52)
MV monitor (cooling)
c-o
Control mode is heating/cooling control
CH
Function
Monitor
Control Monitor range Units
Heating/
cooling
0.0 to 105.0 %
Reference
Reference
Valve opening monitor
v-m
Position proportional type
CH
Function
Monitor
Control Monitor range Units
Position
propor-
tional
-10.0 to 110.0 %
Reference
Reference
