8.9 Input initial setting level (l.0)
8-39
Setting data
● Related setting data
"Input
∗ type" (Input initial setting level) (P.8-36)
"Input
∗ temperature units" (Input initial setting level) (P.8-37)
"Control mode" (Control initial setting level) (P.8-43)
"SP upper limit", "SP lower limit" (Control initial setting level) (P.8-43)
Note: When the input type of remote SP input is set to temperature
input, be sure to set the input type of the main input to the same
setting as the input type of remote SP input.
If the input type of remote SP input is set to temperature input
and the upper and lower limits of remote SP are not the same
as the upper and lower limits of the sensor setting range of the
input type of remote SP input, it will not be possible to obtain a
correct remote SP value.
This setting can be used to not show the digits of the PV after the decimal point.
• When "PV decimal point display" is turned OFF, the digits of the PV
after the decimal point are not shown. When turned ON, the digits
after the decimal point are shown according to the input type setting.
● Related data
"Input
∗ type" (Input initial setting level) (P.8-36)
Remote SP
lower limit
Temperature:
Lower limit of sensor set-
ting range to upper limit of
sensor setting range
Analog:
Larger of -19999 and "dis-
play value equivalent to
input lower limit" to smaller
of 99999 and "display
value equivalent to upper
input limit"
EU -200.0
Setting data Setting range Units Default value
Reference
Reference
PV decimal point display
pvdp
Temperature input
CH
l.0
Function
Setting
Setting range Units Default value
off: OFF
on : ON
− on: ON
Reference
Reference
