14
Specifications for All Function Blocks Section 3-2
The following truth tables outline the internal evaluations performed by the
G9SP-series Controller for each type of input signal. In the tables, 0 indicates
OFF and 1 indicates ON.
Setting: Single Channel
Setting: Dual Channel
Equivalent
Setting: Dual Channel
Complementary
Setting: Dual Channel
Equivalent (2 Pairs)
Input 1 (NC) Output Enable
00
11
Input 1 (NC) Input 2 (NC) Output Enable
000
010
100
111
Input 1 (NC) Input 2 (NO) Output Enable
000
010
101
110
Input 1 (NC) Input 2 (NC) Input 3 (NC) Input 4 (NC) Output Enable
00000
00010
00100
00110
01000
01010
01100
01110
10000
10010
10100
10110
11000
11010
11100
11110
