H1 Multi-Function Digital Input Selections
H1-
Setting
Function Description Page
41
Reverse Run Command (2-Wire
sequence)
Open: Stop
Closed: Reverse run
94
61 External Search Command 1
Closed: Activates Current Detection Speed Search from the max. output
frequency (E1-04)
94
62 External Search Command 2 Closed: Activates Current Detection Speed Search from the frequency reference 94
67 Communications Test Mode Tests the MEMOBUS/Modbus RS-422/485 interface. 95
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
H2: Multi-Function Digital Output MA-MB-MC
Use H2 parameters to assign functions to the multi-function digital output MA-MB-MC.
H2-01
Terminal MA, MB
and MC Function
Selection (relay)
Refer to H2 Multi-Function Digital Output Settings on page 176
for a description of setting values.
0 to 13D E O 40B 95
H2 Multi-Function Digital Output Settings
H2-01
Setting
Function Description Page
0 During Run Closed: A Run command is active or voltage is output 95
1 Zero Speed Closed: Output frequency is 0 95
2 Speed Agree 1
Closed: Output frequency equals the speed reference (plus or minus 2 Hz
hysteresis)
96
4 Frequency Detection 1
Closed: Output frequency is less than or equal to the value in L4-01 with 2 Hz
hysteresis
96
5 Frequency Detection 2 Closed: Output frequency is greater than the value in L4-01 with 2 Hz hysteresis 96
6 Drive Ready
Closed: Drive Ready. The drive is powered up, not in a fault state, and in the
Drive mode
97
7 DC Bus Undervoltage Closed: DC bus voltage is below the Uv trip level 97
8 During Baseblock (N.O.) Closed: There is no output voltage 97
B Torque Detection 1 (N.O.)
Closed: Output current/torque exceeds the torque value set in parameter L6-02
for longer than the time set in parameter L6-03
97
E Fault Closed: Fault occurred (other than CPF00 and CPF01) 97
F Not used
Set this value when the terminal is not used, or when using the terminal in the
pass-through mode
97
10 Minor Fault Closed: An alarm is triggered 97
17 Torque Detection 1 (N.C.)
Open: When the output current exceeds the value set in parameter L6-02 for
more time than is set in parameter L6-03
97
1A Reverse Direction Closed: Drive is running in the reverse direction 98
1E Restart Enabled Closed: An automatic restart is performed 98
3C LOCAL/REMOTE Status
Closed: LOCAL
Open: REMOTE
98
3D Speed Search Closed: Speed search is being executed 98
100 to 102;
104 to 108;
10B, 10E,
110, 117,
11A, 11E,
13C, 13D
H2 Parameter Functions Reversed
Output Switching of 0 to 13D
Reverse the output switching of the multi-function output functions. Set the last
two digits of 1 to reverse the output signal of that specific function
Examples:
Setting
“108” reverses the output of “During baseblock”, which is setting value
08
Setting “13C” reverses the output of “LOCAL/REMOTE Status”, which is
setting “3C”
98
No. Name Description Range Def. Mode
Addr.
Hex
Pg.
H3: Analog Input A1
Use H3 parameters to set the analog input terminal A1.
H3-01
Terminal A1
Signal Level
Selection
Sets the input level for terminal A1.
0: 0 to +10 V (lower limit)
1: 0 to +10 V (no lower limit)
2: 4 to 20 mA
3: 0 to 20 mA
0 to 3 0 O 410 98
H3-03
<22>
Terminal A1 Gain
Setting
Sets the level of the input value when 10 V (20 mA) is input at
terminal A1.
-999.9 to
999.9
100.0% O 411 99
H3-04
<22>
Terminal A1 Bias
Setting
Sets the level of the input value when 0 V (0 or 4 mA) is input at
terminal A1.
-999.9 to
999.9
0.0% O 412 99
H3-13
Analog Input Filter
Time Constant
Sets the primary delay filter time constant for terminal A1 or
potentiometer (optional). Used for noise filtering.
0.00 to 2.00 0.03 s O 41B 101
<22> Parameter can be changed during run.
B.2 Parameter Table
176
SIEP C710606 33A OYMC AC Drive – J1000 User Manual
