Omron KP100L-OD - 12-2010 User Manual

2 Design
2 - 12
Grid Connect Photovoltaic Inverte KP100L-OD-USER’S MANUAL
(2)-2 In the case of you use the rubber bush of the five holes type
The rubber bush of five holes is used for connection with five individual cables.
(2)-3 Use the cable and the wire in the table below
Don't use cables that the loss is more than 1% of nominal power of the inverter.
Refer to the figure below to check possible cable lengths for the different cross-sectional area.
(3) Use the special Rod terminal and crimping pliers for AC wiring like the picture below when connected
with KP100L.
Diameter of cable Cross-sectional area of wire
The rubber bush for one hole 18.5 to 20.5mm
4mm
2
/ AWG12 or more
The rubber bush for five holes 3.5 to 4.0mm
4mm
2
/ AWG12
Cross-
sectional area of wire
Rod terminal
(Phoenix Contact)
crimping pliers
(Phoenix Contact)
4 mm
2
AI 4-10 GY CRIMFFOX 6, CRIMPFOX 10s
6mm
2
AI 6-12 YE CRIMFFOX 6, CRIMPFOX 10s
10 mm
2
AI 10-12 RD CRIMPFOX 10s
Rubber Bush (five holes)
Cap
0.0%
0.5%
1.0%
1.5%
2.0%
Cable length [m]
Cable lossses
4[mm2]
6[mm2]
10[mm2]
0
20
40
60
80
100
12mm or more
Cut in 10mm
Rod terminal
