5-6 Initialization/Setting Screen
5-16
Removing the Destination Drive
This function is used to stop the device so that the drive, which was specified as the
destination to save history data, can be safely removed (Perform the same process as that
of Windows’ safely remove hardware)
Stop the device by using operations in the Initialize Tab Page as follows.
1. Click the Remove Button in the Destination File Path field.
2. The following dialog box will be displayed when it is safe to remove the drive.
3. Confirm that it is safe to remove the drive, and remove the removable drive.
4. If a removable drive is not being used as a destination, the following dialog box will be
displayed.
N
N
N
o
o
o
t
t
t
e
e
e
In order to use the removable drive again after the Ready to Remove is shown, insert the
removable drive into the NS-Runtime environment again. Once the Ready to Remove is
shown, the NS-Runtime cannot access a removable drive until the removable drive is
inserted again.
When turning ON $SB49 in system memory from the host and when it is safe to remove a
memory card, $SB50 will be turned ON. While the $SB50 is ON, a memory card inserted
into the NS-Runtime environment can be removed. For details, refer to 2-4 System Memory
in NS series Programming Manual.
