3-5 Converting Projects
3-14
3-5 Converting Projects
Converting projects to supported PT models.
N
N
N
o
o
o
t
t
t
e
e
e
To convert projects from the NS Series (NS15/12/10/8/7/5, NSJ12/10/8/5, NSH5) to the NS-
Runtime (NSA Series and NS-Runtime), projects before conversion must be version 6.6 or later.
When converting projects whose versions are earlier than version 6.6, change the project
versions into version 6.6 or higher the Tools Menu – Convert – Version.
1. Select the Tools Menu – Convert – Model.
2. The Convert Model Dialog Box will be displayed. Select NS-Runtime as the model and
click the OK Button.
3. Messages will be displayed to confirm the functional differences between NS Series and
NS-Runtime. Check the information and if you still want to convert, click the OK Button.
4. Specify a name for the converted project in the Convert to Dialog Box. Click the Save
Button to convert the model.
To Next Page
