3-1 Creating Projects
3-2
3-1 Creating Projects
3-1-1 Creating New Projects
This section describes procedures for creating new projects in order to start creation.
1. Select the File Menu – New Project, or select the New Project under the toolbar.
2. New Project Dialog Box will be displayed. Select an NS Series Model and a System
Version. Click the OK Button.
Select the NSA12/15-TX01[] or NS-Runtime from the Model and the 6.6 or later from the
System Version to use it with the NS-Runtime.
2
1
No Item Description
1 Model Select the NSA12/15-TX01[] or the NS-Runtime to create an NS-
Runtime targeted project.
Select the NS-Runtime when using the NS-Runtime in an
environment other than the NSA Series.
2 System Version Select the 6.6 or later to create a project for the NS-Runtime.
N
N
N
o
o
o
t
t
t
e
e
e
When the NSA12/15-TX01[] or the NS-Runtime is chosen from the Model, the System
Version 6.6 or later can only be selected.
When creating a project for other PT models, refer to the Creating Projects in the CX-
Designer Online Help.
3. New Screen Dialog Box will be displayed. Input the screen number and title. Click the OK
Button.
4. When a new screen is opened, start creating a screen.
N
N
N
o
o
o
t
t
t
e
e
e
When using the NS-Runtime in an environment other than the NSA Series, set the NS-
Runtime’s main window size from the System Setting Dialog Box. For further information,
please refer to 3-2 System Settings.
For the NSA Series, the main window size is fixed at 1024 x 768 dots.
