4-3 Alarm/Event Setting
4-15
4-3 Alarm/Event Setting
When alarm/event occurs, PDF files specified with Document Display can be displayed with
the NS-Runtime. In response to this new function, setting items to specify a desired PDF file
are added to the Alarm/Event Details.
This section describes added items only. For the other items, refer to 2-14 Alarm/Event in the
NS Series Programming Manual.
1. Select the Alarm/Event Setting under the PT Menu with the CX-Designer.
2. Alarm Event Dialog Box will be displayed. Click the Add or Edit Button.
3. Alarm/Event Details Dialog Box will be displayed.
No. Item Description
1 Display the document on
a document display
object
Select this check box to display PDF file on a document display
object when an alarm/event occurs.
Click the Set Button to display the Document Table Setting
Dialog Box. Then select a document to display.
Displays whether or not a
document is set to display and
document numbers.
1
To Next Page
