1-3 CX-Designer Menu List
1-6
1-3 CX-Designer Menu List
The NS-Runtime has the following pull-down menus that are different from CX-Designer’s.
Menus not described here are the same as the existing CX-Designer’s menus.
File Menu
There are following changes in the File Menu.
Item Function Reference
New project
Creates new projects. The NSA12/15-TX01[] and
the NS-Runtime are added.
Select the NS-Runtime when using the NS-
Runtime in an environment other than NSA Series.
3-1
Print
Document Table Setting is added to the Print Item
Details.
−
Data Transfer Security This menu cannot be used.
−
• Edit Menu
There is no change in the Edit Menu.
• Find Menu
There is no change in the Find Menu.
• View Menu
There is a following change in the View Menu.
Item Function Reference
Show Touch Points This menu cannot be used.
−
• PT Menu
There are following changes in the PT Menu.
Item Function Reference
Transfer
When the CX-Designer and NS-Runtime is
installed in the same environment, a function to
copy project data to the NS-Runtime project
storage folder will be added.
6-1
System Setting
Sets an NS-Runtime’s parameter operating.
The following changes are made.
-A folder can be specified to save history data.
-Maximum screen size can be set.
3-2
Alarm/Event Setting
Registers and modifies the alarm/event.
Setting items for the display document table are
added, which enables to show on a document
display object when an alarm occurs.
4-3
Data Log Setting Always logging can be set up to 160,000 points. 4-4
Document Table Setting
Registers document files (PDF files) to display on
document display objects.
4-2-2
Screen/Sheet Properties
Setting ranges were changed as follows.
-NSA Series: 1024 x 768 dots max.
-Other than NSA Series: 3840 x 2400 dots max.
3-4
To Next Page
