1-2 About NS-Runtime
1-5
1-2-3 System Configuration
This section describes the system configuration used for the NS-Runtime.
The NS-Runtime runs on Windows XP, Vista, or 7 and the NSA Series.
Twisted- pair cable
Printer
Printer that can be used
with Windows
Host
Keypad, Mouse
RS-232C cable (15 m max.)
RS-422A cable (500 m max.)
RS-232C/422A Adapter
Ethernet cable
NSA Series and
NS-Runtime
Controller Link
Interface Unit
Enables Controller Link
communications with a
host.
CX- Designer
Personal computer
Computer running Windows
Data Transfer via
Memory Card
Bar Code Reader
Reads bar codes as
text string data.
NS-Runtime
Personal computer
Computer running
Windows
N
N
N
o
o
o
t
t
t
e
e
e
The computer must support RS-442A to be able to connect using RS-422A.
