5-6 Initialization/Setting Screen
5-27
Buzzer Sound
This function is used to set whether to sound a buzzer at times such as when a command
from the host is received or an error occurs.
ON: Buzzer turns ON when a command is received from the host or an error occurs.
OFF: Buzzer is OFF.
ERR ON: Buzzer turns ON when an error occurs only.
N
N
N
o
o
o
t
t
t
e
e
e
Other commands and settings associated with the buzzer exist, but the settings here have
the highest priority.
When the buzzer is set to ON or ERR ON, the buzzer will be also heard when messages are
displayed with a cross (X) or exclamation mark (!) icon.
For details on the buzzer function, refer to 2-20-6 Buzzer Function in the NS Series
Programming Manual.
Set the buzzer to ON/OFF/ERROR ON by using operations from the PT Tab Page as follows.
1. Select either ON, OFF, or ERROR ON for the buzzer sound.
2. After setting, click the Write Button to save the setting. (For details on the write button,
refer to Writing on page 5-29.)
Backlight
This function is used to set backlight brightness. (NSA Series only)
Set the backlight brightness by using operations from the PT Tab Page as follows.
1. Select the High, Middle or Low for the Backlight.
2. After setting, click the Write Button to save the setting. (For details on the write button,
refer to Writing on page 5-29.)
