2-9SectionCharacter String Display
150
The relationship between the properties of a character string display and the dis-
played character string is indicated below.
Properties
General
Position Coordinates of the top left corner of the field in which the
character string is displayed.
Font Type Font for the characters
Standard/Half Height
Scale Scale at which the character string is displayed (Enlarged dis-
play, page 151).
11 (Equal), 12 (High), 21 (Wide), 22, 33, 44,
88
Smoothing Whether or not smoothing is used for characters with a scale of
22 or larger (Smoothing, page 151).
Check mark (smoothing executed)/
No check mark (smoothing not executed)
Attribute Display mode for the character string (Display attributes and
drawing result, page 152).
Standard/Flash/Inverse Flash
Color
Foreground Display color of the text (Colors other than black and white are
available with the NT31C and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Background Background color of the text (Colors other than black and white
are available with the NT31C and NT631C only.)
Black/Blue/Red/Magenta/Green/Cyan/Yellow/White
Settings
Reference
Indirect
Reference
Method for referencing the character string memory table entry
whose contents are to be displayed (Direct reference and indi-
rect reference, page 152)
Check mark (Indirect Reference)/
No check mark (Direct Reference)
Table Entry Numeral memory table entry number referenced for display
(Direct reference and indirect reference, page 152)
 When Direct Reference is specified:
Table entry number of the numeral memory table entry in
which the character string to be displayed is stored.
 When Indirect Reference is specified:
Table entry number of the numeral memory table entry in
which the number of the character string memory table entry
whose contents are to be displayed is stored.
Length Number of displayed characters
NT21: 1 to 32
NT31/NT31C: 1 to 40
NT631/NT631C: 1 to 40
Background color
ABCDE
Position
Foreground color
Common Attributes
