Appendix BCompatibility with Screen Data of Other PT Models
444
Item NT31/NT31C, NT631/NT631CNT30/NT30C, NT620S/NT620C/NT625C
Pop-up
window
function
touch
switch
Only Keyboard screen can be controlled.
Window display position can not be changed.
Local window1 or local window2 can be controlled.
Window display position can be changed.
Window
move func-
tion touch
switch
Not available Available
System
program
for
memory
link
Memory link only Shared with OMRON/Memory link (-V1 and later versions)
Screen
data for
memory
link
OMRON screen data (data area allocation only, no allocation check) Memory link screen data (Allocation check is possible.)
Device
Monitor
function
Not available Can be used to switch the PC’s operating mode, display/change
contents of PC words, and display the error log.
Mathemat-
ical func-
tion
Not available Can be used to automatically execute up to 256 formulas registered
in mathematical table.
(Operands (results) are automatically read from (written to) numeral
memory table entries or PC words.)
High-
speed 1:N
NT Link
Not available (Only the standard 1:N NT Link is supported.) Available (Both the standard and high-speed 1:N NT Link are
supported.)
Recipe
function
None Normal screen: 1 max.; Multiple screens: 8 max.; Window screens:
Not possible
Accessible
CS/CJ-se-
ries data
areas
CIO area
TIM area (timer PVs)
CNT area (counter PVs)
DM area
EM area (current bank only)
CIO area
HR area
WR area (work areas)
TK area (task flags)
TIM area (timer PVs)
TU area (timer completion flags)
CNT area (counter PVs)
CU area (counter completion flags)
DM area
EM area (current bank, banks 0 to C)
Apart from the above, due to difference between PT models, it may be necessary to modify screen data and pro-
grams at the host. For details, refer to the NT-series Support Tool Version 4. for Windows Operation Manual
(V061-E1-).
