Omron NX-ECC201 User Manual

Appendices
A - 38
NX-series EtherCAT Coupler Unit User’s Manual (W519)
• This object tells whether NX Units are registered in the Unit configuration information.
• The number shown at the end of each object name for subindexes 01 to 04 hex gives the number of
NX Units for which the status is acquired. The data assignments are given in the following table. The
number in each cell is the NX Unit number of the corresponding NX Unit. NX Unit number 0 repre-
sents the EtherCAT Coupler Unit.
The applicable bit is 0 (FALSE) if the Unit is not registered, or 1 (TRUE) if it is registered. NX Units
that are set to Disable are given as being registered.
Refer to NX Unit Registration Status under Details of I/O Data in the EtherCAT Coupler Unit on page
9-16 for details on this status.
Index
(hex)
Subin-
dex
(hex)
Object name Default Data range Unit
Data
attribute
Size Access
PDO
map-
ping
Com-
plete
access
3003 --- NX Unit Registration
Status
--- --- --- --- --- --- --- Not pos-
sible.
00 Number of entries 04 hex 04 hex --- --- 1 byte
(U8)
RO Not
possi-
ble.
---
01 NX Unit Registration
Status 15
0000 hex 0000
to
FFFF hex
--- --- ARRAY[0.
.1] OF
BYTE
RO Possi-
ble.
---
02 NX Unit Registration
Status 31
00000000
hex
00000000
to
FFFFFFFF hex
--- --- ARRAY[0.
.3] OF
BYTE
RO Possi-
ble.
---
03 NX Unit Registration
Status 63
00000000000
00000 hex
000000000000
0000
to
FFFFFFFFFFF
FFFFF hex
--- --- ARRAY[0.
.7] OF
BYTE
RO Possi-
ble.
---
04 NX Unit Registration
Status 125
00000000000
00000000000
0000000000
hex
000000000000
000000000000
00000000
to
3FFFFFFFFFF
FFFFFFFFFFF
FFFFFFFFFF
hex
--- --- ARRAY[0.
.15] OF
BYTE
RO Possi-
ble.
---
15 14 13 12
+0 15 14 13 12
+1 31 30 29 28
+2 47 46 45 44
+3 63 62 61 60
+4 79 78 77 76
+5 95 94 93 92
+6 111 110 109 108
+7 125 124
11 10
11 10 9 8 7 6 5 4 3 2 1 0
27 26 25 24 23 22 21 20 19 18 17 16
43 42 41 40 39 38 37 36 35 34 33 32
59 58 57
75 74 73
91 90 89
107 106 105
123 122 121
56 55 54 53 52 51 50 49 48
72 71 70 69 68 67 66 65 64
88 87 86 85 84 83 82 81 80
104 103 102 101 100 99 98 97 96
120 119 118 117 116 115 114 113 112
09 08 07 06 05 04 03 02 01 00
Bit position
Word
offset
