Omron NX102 series User Manual

1-5
1 Introduction
NJ/NX-series CPU Unit Built-in EtherCAT Port User’s Manual (W505)
1-2 System Configuration and
Configuration Devices
1
1-2-1 System Configuration
 Input Port
This port is used to input EtherCAT communications data. Always connect it to the output port on
another device. Normal communications will not be possible if you connect to the input port on
another device.
 EtherCAT Slaves
Each EtherCAT slave outputs the output data that it received from the EtherCAT master through the
EtherCAT network. It also sends input data to the EtherCAT master through the EtherCAT network.
• Each slave has one input port and at least one output port.
• In the EtherCAT network, you can use the salves and Junction Slaves that are listed below in total
up to the maximum number of slaves.
• Assign node addresses to the slaves and Junction Slaves. The node address can be any value
within the settable node address range, and can be assigned without any distinction between the
slaves and Junction Slaves. But any node address should not be used more than once.
• The EtherCAT slaves can be classified into two: whether they support synchronization based on
a distributed clock (DC) or not.
a) Non-synced Slaves
These slaves perform sequence control that does not require synchronization between them.
Digital I/O Slaves and Analog I/O Slaves are among this type. They do not support a distrib-
uted clock (DC).
b) Synced Slaves
These slaves are synchronized based on the distributed clock (DC). Servo Drives and
encoder input slaves are among this type.
Note 1 Refer to 1-3-1 Performance Specifications for details on the maximum number of slaves
and the settable node address range.
2 The slaves are synchronized even when multiple non-synced slaves and Junction Slaves
are connected.
The following tables lists some of the OMRON EtherCAT slaves that are available.
Name Type Model
Synced/
Non-synced
Slaves
Reference
Clock*
1
Assigning
an axis
Digital I/O Slaves Slaves with screw
terminals and 2-tier
terminal block
GX-D161/OC1601 Non-synced
Slaves
Exist Not
possible
Slaves with screw
terminals and 3-tier
terminal block
GX-ID162/OD162/MD162 Non-synced
Slaves
Exist Not
possible
Slaves with e-CON
connectors
GX-D168/D328 Non-synced
Slaves
Exist Not
possible
Analog I/O
Slaves
Slaves with screw
terminals and 2-tier
terminal block
GX-AD0471/DA0271 Non-synced
Slaves
Exist Not
possible
NX-series Ether-
CAT Coupler Unit
NX Series
NX-ECC201
*2
NX-ECC202
*3
NX-ECC203
*4
Synced
Slaves
Exist Not possible
(Some of the
connected
NX Units can
be assigned
to an axis.)
Multifunctional,
Compact Inverters
MX2 Series 3G3MX2 with
EtherCAT Communications Unit
3G3AX-MX2-ECT
Non-synced
Slaves
Exist Not
possible
Advanced General-
purpose Inverters
RX Series 3G3RX-V1 with
EtherCAT Communications Unit
3G3AX-RX-ECT
Non-synced
Slaves
Exist Not possible
