1 Introduction
1-6
NJ/NX-series CPU Unit Built-in EtherCAT Port User’s Manual (W505)
*1 Shows whether or not the slave provides a reference clock. A slave or a master that provides a reference clock is
required for a system configuration that enables synchronization between slaves based on a distributed clock (DC). When
you connect a slave that supports the reference clock, you must meet some conditions. Refer to 4-1-1 Supported Network
Topologies for detail on the conditions.
*2 A CPU Unit with unit version 1.05 or later and Sysmac Studio version 1.06 or higher are required.
*3 A CPU Unit with unit version 1.07 or later and Sysmac Studio version 1.08 or higher are required.
*4 A CPU Unit with unit version 1.07 or later and Sysmac Studio version 1.11 or higher are required.
EtherCAT Junction Slave
This is a special Unit for branching EtherCAT network wiring. Cascade connections are possible
within the range of node addresses that the EtherCAT master can handle.
Each Junction Slave has one input port and more than one output port. The output ports on each
Junction Slave can be connected to another Junction Slave or other EtherCAT slaves.
The Junction Slave supports the reference clock that is required for a system configuration that
enables synchronization between slaves based on a distributed clock (DC).
The following models are examples of some of the OMRON EtherCAT slaves.
Precautions for Safe Use
You cannot use standard Ethernet hubs or repeater hubs with EtherCAT communications. If you
use one of these, a major fault level error or other error may occur.
AC Servo Drive G5-series Servo
Drive with EtherCAT
communications
R88M-K/R88D-KN-ECT Synced
Slaves
Exist Possible
Linear Servo Drives G5-series Linear
Servo Drives with
EtherCAT communi-
cations
R88L-EC/R88D-KN-ECT-L Synced
Slaves
Exist Possible
Encoder Input
Slaves
Slave with 3-tier ter-
minal block
GX-EC0211/EC0241 Synced
Slaves
Exist Possible
Vision Sensors FH Series FH-1
FH-3
Synced
Slaves
Exist Not possible
Specialized Vision
Sensors for Posi-
tioning
FQ-M-series Sensors
with EtherCAT Com-
munications
FQ-MS12(-)-ECT Synced
Slaves
Exist Not possible
FZM1-series Vision
Sensors
FZM1-35-ECT Synced
Slaves
Exist Not possible
Digital Sensor Com-
munications Unit
E3NW Series E3NW-ECT Synced
Slaves
Exist Not possible
Fiber Sensor Com-
munications Unit
E3X Series E3X-ECT Synced
Slaves
Exist Not possible
Confocal Fiber Type
Displacement Sen-
sors
ZW Series ZW-CE1 Synced
Slaves
Exist Not possible
Slave type/name Number of ports Model
EtherCAT Junction Slave 3 ports GX-JC03
6 ports
GX-JC06
Name Type Model
Synced/
Non-synced
Slaves
Reference
Clock*
1
Assigning
an axis
