10.6 Drive Exterior and Mounting Dimensions
380 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
■ 4089, 4103
Figure 10.14 Exterior and Mounting Dimensions Diagram 5
Table 10.31 400 V Class (UL Type 1)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W3
(max.)
H0 H1 H2 H3 H5 t1 t2 d
4089
259
(10.20)
580
(22.83)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
10
(0.394)
450
(17.72)
424
(16.69)
16
(0.630)
130
(5.12)
21
(0.827)
2.3
(0.091)
2.3
(0.091)
M6
25
(55.11)
4103
259
(10.20)
580
(22.83)
280
(11.02)
166
(6.54)
114
(4.49)
170
(6.69)
165
(6.50)
10
(0.394)
450
(17.72)
424
(16.69)
16
(0.630)
130
(5.12)
21
(0.827)
2.3
(0.091)
2.3
(0.091)
M6
29
(63.93)
