Omron Q2A Series Technical Manual

Specifications
10
10.6 Drive Exterior and Mounting Dimensions
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 381
■ 4140, 4168
Figure 10.15 Exterior and Mounting Dimensions Diagram 6
Table 10.32 400 V Class (UL Type 1)
Model
Dimensions mm (in.)
Weight
kg (lb.)
W H D D1 D2 W1 W2
W3
(max.)
H0 H1 H2 H3 H5 t1 t2 d
4140
268
(10.55)
700
(27.56)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
10
(0.394)
543
(21.38)
516
(20.31)
17.5
(0.689)
157
(6.18)
20.5
(0.807)
2.3
(0.091)
2.3
(0.091)
M8
43
(94.80)
4168
268
(10.55)
700
(27.56)
335
(13.19)
186
(7.32)
149
(5.87)
190
(7.48)
182
(7.17)
10
(0.394)
543
(21.38)
516
(20.31)
17.5
(0.689)
157
(6.18)
20.5
(0.807)
2.3
(0.091)
2.3
(0.091)
M8
44
(97.00)
