Page #391 background imageLoading...
Page #391 background image
Specifications
10
10.8 Peripheral Devices and Options
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 391
*1 Contact the manufacturer or your nearest sales representative for more information.
Types of Option Cards and Connectors
Option PCB Available Connector Ports Number of Options Permitted
PG-B3, PG-X3 CN5-C (CN5-B)
2
*1
PG-F3
*2
and PG-RT3
*2
CN5-C
1
AO-A3, DO-A3 CN5-A, B, and C
1
AI-A3
*3
, DI-A3
*3
, SI-EL3, SI-EN3, SI-EP3, SI-ES3 CN5-A
1
*1 To connect only one PG option card, use the CN5-C connector. To connect two PG option cards, use the CN5-C and CN5-B
connectors.
*2 If you use the motor switching function, you cannot use this option.
*3 To use AI-A3 and DI-A3 input statuses as monitors, connect the option cards to one of CN5-A, CN5-B, or CN5-C. Use U1-21, U1-
22, and U1-23 to confirm the AI-A3 input status. Use U1-17 to confirm the DI-A3 input status.
