Page #424 background imageLoading...
Page #424 background image
11.7 F: OPTIONS
424 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
No.
(Hex.)
Name Description
Default
(Range)
Ref.
F6-07
(03A8)
Multi-Ref@NetRef/
ComRef
Sets the function that enables and disables the multi-step speed reference when the
frequency reference source is NetRef or ComRef (communication option card or
Modbus communications).
0 : Disable MultiStep References
1 : Enable MultiStep References
0
(0, 1)
648
F6-08
(036A)
Comm Par
RST@Initialize
Sets the function to initialize F6-xx and F7-xx parameters when the drive is initialized
with A1-03 [Init Parameters].
0 : Retain Pars - No Reset
1 : Factory Default - Reset
0
(0, 1)
649
F6-10
(03B6)
CCLink Node Address
Sets the node address for CC-Link communication. Restart the drive after changing this
setting.
Note:
Be sure to set a node address that is different than all other node addresses. Do not
set this parameter to 0. Incorrect parameter settings will cause AEr [Station Address
Setting Error] errors and the L.ERR LED on the option will come on.
0
(0 - 64)
649
F6-11
(03B7)
CCLink Comm Speed
Sets the communication speed for CC-Link communication. Restart the drive after you
change this setting.
0 : 156 kbps
1 : 625 kbps
2 : 2.5 Mbps
3 : 5 Mbps
4 : 10 Mbps
0
(0 - 4)
649
F6-14
(03BB)
BUS Err. AutoReset
Sets the automatic reset function for bUS [Option Communication Errors].
0 : Disabled
1 : Enabled
0
(0, 1)
649
F6-16
(0B8A)
Gateway Mode
Sets the gateway mode operation and the number of connected slave drives.
0 : Disabled
1 : 1 Slave Drive
2 : 2 Slave Drives
3 : 3 Slave Drives
4 : 4 Slave Drives
0
(0 - 4)
650
F6-20
(036B)
MLII Address
Sets the station address for MECHATROLINK communication. Restart the drive after
changing this setting.
Note:
The setting range changes if using MECHATROLINK-II or MECHATROLINK-
III:
MECHATROLINK-II (SI-T3) range: 20 - 3F
MECHATROLINK-III (SI-ET3) range: 03 - EF
Be sure to set a node address that is different than all other node addresses.
Incorrect parameter settings will cause AEr [Station Address Setting Error] errors
and the L.ERR LED on the option will come on.
The drive detects AEr errors when the station address is 20 or 3F.
0021h
(MECHATROLINK-
II0020h - 003Fh
MECHATROLINK-
III0003h - 00EFh)
652
F6-21
(036C)
MLII Frame Size
Sets the frame size for MECHATROLINK communication. Restart the drive after you
change this setting.
0 : 32-byte
1 : 17-byte
0
(0, 1)
653
F6-22
(036D)
MLII Link Speed
Sets the communications speed for MECHATROLINK-II. Restart the drive after you
change this setting.
Note:
This parameter is only available with the MECHATROLINK-II option.
0 : 10 Mbps
1 : 4 Mbps
0
(0, 1)
653
F6-23
(036E)
MLII Mon Sel (E)
Sets the Modbus register used for the monitor functions of INV_CTL (drive operation
control command) and INV_I/O (drive I/O control command). Restart the drive after
you change this setting.
0000h
(0000h - FFFFh)
653
F6-24
(036F)
MLII Mon Sel (F)
Sets the Modbus register used for the monitor functions of INV_CTL (drive operation
control command) and INV_I/O (drive I/O control command). Restart the drive after
you change this setting.
0000h
(0000h - FFFFh)
653
