Parameter List
11
11.8 H: TERMINALS
SIEPYEUOQ2A01A AC Drive Q2A Technical Manual 431
■ H1-xx: Multi-Function Digital Input Setting Values
Setting Function Description Ref.
0 Through Mode
Setting for terminals that are not being used or terminals being used in through mode.
669
1 Forward Run
Sets the Forward Run command for 2-wire sequence 1. Set this function and H1-xx = 2 [Reverse Run] together.
ON : Forward Run
OFF : Run Stop
Note:
• Turning ON the Forward Run command terminal and the Reverse Run command terminal will cause alarm
EF [FWD/REV Run Command Input Error] and the motor will ramp to stop.
• Initialize the drive with a 2-wire sequence to set the Forward Run command to terminal DI1.
• This function will not operate at the same time as H1-xx = 3, 4 [Run Command, FWD/REV Cmd].
670
2 Reverse Run
Sets the Reverse Run command for 2-wire sequence 1. Set this function and H1-xx = 1 [Forward Run] together.
ON : Reverse Run
OFF : Run Stop
Note:
• Turning ON the Forward Run command terminal and the Reverse Run command terminal will cause alarm
EF [FWD/REV Run Command Input Error] and the motor will ramp to stop.
• Initialize the drive with a 2-wire sequence to set the Reverse Run command to terminal DI2.
• This function will not operate at the same time as H1-xx = 3, 4 [Run Command, FWD/REV Cmd].
670
3 Run Command
Sets the Run command for 2-wire sequence 2. Set this function and H1-xx = 4 [FWD/REV Cmd] together.
ON : Run
OFF : Stop
Note:
This function will not operate at the same time as H1-xx = 1, 2 [Forward Run, Reverse Run].
670
4 FWD/REV Cmd
Sets the direction of motor rotation for 2-wire sequence 2. Set this function and H1-xx = 3 [Run Command]
together.
ON : Reverse
OFF : Forward
Note:
This function will not operate at the same time as H1-xx = 1, 2 [Forward Run, Reverse Run].
670
5 3-Wire Seq.
Sets the direction of motor rotation for 3-wire sequence.
671
6 Jog Reference
Sets the drive to use the JOG Frequency Reference (JOG command) set in d1-17. The JOG Frequency Reference
(JOG command) overrides Frequency References 1 to 16 (d1-01 to d1-16).
671
7 Jog Forward
Sets the command to operate the motor in the forward direction at the Jog Frequency set in d1-17 [Jog Reference].
672
8 Jog Reverse
Sets the command to operate the motor in the reverse direction at the Jog Frequency set in d1-17 [Jog Reference].
672
9 Ext Ref 1/2
Sets the drive to use Run command source 1/2 or Reference command source 1/2 when in REMOTE Mode.
ON : b1-15 [Freq. Ref. Sel. 2], b1-16 [Run Comm. Sel 2]
OFF : b1-01 [Freq. Ref. Sel. 1], b1-02 [Run Comm. Sel 1]
672
A MultSpd Ref1
Uses speed references d1-01 to d1-08 [Reference 1 to Reference 8] to set a multi-step speed reference.
672
B MultSpd Ref2
Uses speed references d1-01 to d1-08 [Reference 1 to Reference 8] to set a multi-step speed reference.
672
C MultSpd Ref3
Uses speed references d1-01 to d1-08 [Reference 1 to Reference 8] to set a multi-step speed reference.
673
D MultSpd Ref4
Sets the command to switch d1-09 to d1-16 [Reference 9 to Reference 16] with multi-step speed references 1, 2
and 3.
673
E Offset Frq 1
Sets the function to add the offset frequency set in d7-01 [Offset Frq 1] to the frequency reference when the
terminal activates.
673
F Offset Frq 2
Sets the function to add the offset frequency set in d7-02 [Offset Frq 2] to the frequency reference when the
terminal activates.
673
10 Offset Frq 3
Sets the function to add the offset frequency set in d7-03 [Offset Frq 3] to the frequency reference when the
terminal activates.
673
