Omron Q2A Series Technical Manual

11.20 Parameters Changed by PM Motor Code Selection
502 SIEPYEUOQ2A01A AC Drive Q2A Technical Manual
No. Name Unit Motor Code (setting value of E5-01)
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4 4.4
C5-17 Motor Inertia kgm
2
0.044 0.054 0.063 0.113 0.137 0.252 0.30 0.41
L3-24
*1
Acc@Rated Torque s 0.099 0.098 0.096 0.126 0.124 0.188 0.186 0.184
n5-02
Mot Inertia
Acceleration Time
s 0.099 0.098 0.096 0.126 0.124 0.188 0.186 0.184
n8-49 Heavy Load Id Current % -15.1 -14.3 -15.3 -11.3 -14.5 -13.2 -22.6 -11.9
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.15 SST4 Series Motor Code Setting for Specification of 400 V at 1750 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 2247 2248 2249 224A 224C 224D 224E
Voltage Class V 400 400 400 400 400 400 400
Capacity kW 90 110 132 160 200 220 300
Motor Rotation Speed min
-1
1750 1750 1750 1750 1750 1750 1750
E5-02
PM Mot Rated Power
(kW)
kW 90.00 110.00 132.00 160.00 200.00 250.00 300.00
E5-03
PM Mot Rated Current
(FLA)
A 153.1 184.4 229.2 269.8 346.9 421.9 520.8
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 0.019 0.017 0.012 0.008 0.005 0.004 0.002
E5-06
PM d-Axis Inductance
(mH/Phase)
mH 1.51 1.43 1.13 0.96 0.65 0.67 0.40
E5-07
PM q-Axis Inductance
(mH/Phase)
mH 1.76 1.92 1.54 1.26 0.88 0.74 0.52
E5-09
PM BackEMF Vpeak
(mV/(rad/ s))
mVs/rad 538.3 590.9 548.2 603.9 556.8 593.1 495.4
E5-24
PM BackEMF L-L Vrms
(mV/rpm)
mV/(r/min) 0.0 0.0 0.0 0.0 0.0 0.0 0.0
E1-04 Max Output Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-05 Max Output Voltage V 380.0 380.0 380.0 380.0 380.0 380.0 380.0
E1-06 Base Frequency Hz 87.5 87.5 87.5 87.5 87.5 87.5 87.5
E1-09 Min Output Frequency Hz 4.4 4.4 4.4 4.4 4.4 4.4 4.4
C5-17 Motor Inertia kgm
2
0.55 0.82 0.96 1.60 1.95 2.82 3.70
L3-24
*1
Acc@Rated Torque s 0.205 0.250 0.244 0.336 0.327 0.379 0.414
n5-02
Mot Inertia Acceleration
Time
s 0.205 0.250 0.244 0.336 0.327 0.379 0.414
n8-49 Heavy Load Id Current % -8.6 -14.8 -17.5 -12.5 -14.7 -5.1 -16.3
*1 Default settings vary depending on the setting of o2-04 [Drive KVA Selection].
Table 11.16 SST4 Series Motor Code Setting for Specification of 400 V at 1450 min
-1
(r/min)
No. Name Unit Motor Code (setting value of E5-01)
E5-01
PM Mot Code Selection - 2332 2333 2335 2336 2338 233A 233B 233D
Voltage Class V 400 400 400 400 400 400 400 400
Capacity kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11
Motor Rotation Speed min
-1
1450 1450 1450 1450 1450 1450 1450 1450
E5-02
PM Mot Rated Power
(kW)
kW 0.4 0.75 1.5 2.2 3.7 5.5 7.5 11.0
E5-03
PM Mot Rated Current
(FLA)
A 0.91 1.67 3.02 4.74 7.08 10.21 13.96 20.5
E5-04 PM Mot Pole Count - 6 6 6 6 6 6 6 6
E5-05
PM Mot Resistance
(Ohms/Phase)
Ω 12.616 7.340 2.724 1.232 1.509 1.112 0.720 0.393
